Mini Digger For Sale Ireland
Strong Carry And Dig Overall Performance Helps You Get The Job Executed Faster. The Retractable Undercarriage Lets You Get Right Of Entry To And Work In The Tightest Areas. Dig-To-Blade And Dozer Glide Facets Permit For Convenient Smooth Up.
Product Details
Equipped With Aspects Such As Auto Idle, Auto Engine Shutdown,
And Environment Friendly Hydraulics With a Variable Displacement Pump,
The Mini Excavator Was Once Designed With Decreasing Your Running Prices In Mind.
| Model | TWE10 |
| ENGINE | |
| Emission Standard | Tier 3/ Stage III |
| Make /Model | KOOP( KD192F-1) |
| Power /Rotation speed | 7kw/3000rpm |
| Number of cylinder | 1 |
| TRACK SYSTEM | |
| Maximum Travel speed | 1.9km/h |
| Width of track shoe(Rubber &steel track) | 180mm |
| Number of track shoe per side(steel track only) | |
| Number of upper roller per side | 0 |
| Number of bottom roller per side | 2 |
| PERFORMANCE PARAMETER | |
| Standard Bucket capacity | 0.023m³ |
| Swing speed | 13 r/min |
| Maximum Grade ability | 58%(30°) |
| Maximum Bucket digging force | 7.2 KN |
| Maximum Arm digging force | 4.6 KN |
| Hydraulic system pressure | 16MPa |
| Machine weight | 920kg |
| MACHINE SIZE | |
| Overall dimension (L*W*H) | 2840mm*880mm*2220mm |
| Axle base/Track length on ground | 1233mm |
| Track gauge | 660mm |
| Minimum Ground clearance | 132mm |
| Swing radius at tail | 800mm |
| WORKING RANGE | |
| Maximum Digging height | 2600mm |
| Maximum Dumping height | 1830mm |
| Maximum Digging depth | 1715mm |
| Maximum Vertical digging depth | 1590mm |
| Maximum Digging radius | 3065mm |
| Minimum swing radius | 1480mm |
| Maximum Lifting height of blade | |
| Maximum Cutting depth of blade | |
| Boom swing angle(Left/Right) | |
| Shipping method | 6 units in 20GP container 24units in 40GP container |
| Model | TWE10 |
| ENGINE | |
| Emission Standard | Tier 3/ Stage III |
| Make /Model | KOOP( KD192F-1) |
| Power /Rotation speed | 7kw/3000rpm |
| Number of cylinder | 1 |
| TRACK SYSTEM | |
| Maximum Travel speed | 1.9km/h |
| Width of track shoe(Rubber &steel track) | 180mm |
| Number of track shoe per side(steel track only) | |
| Number of upper roller per side | 0 |
| Number of bottom roller per side | 2 |
| PERFORMANCE PARAMETER | |
| Standard Bucket capacity | 0.023m³ |
| Swing speed | 13 r/min |
| Maximum Grade ability | 58%(30°) |
| Maximum Bucket digging force | 7.2 KN |
| Maximum Arm digging force | 4.6 KN |
| Hydraulic system pressure | 16MPa |
| Machine weight | 920kg |
| MACHINE SIZE | |
| Overall dimension (L*W*H) | 2840mm*880mm*2220mm |
| Axle base/Track length on ground | 1233mm |
| Track gauge | 660mm |
| Minimum Ground clearance | 132mm |
| Swing radius at tail | 800mm |
| WORKING RANGE | |
| Maximum Digging height | 2600mm |
| Maximum Dumping height | 1830mm |
| Maximum Digging depth | 1715mm |
| Maximum Vertical digging depth | 1590mm |
| Maximum Digging radius | 3065mm |
| Minimum swing radius | 1480mm |
| Maximum Lifting height of blade | |
| Maximum Cutting depth of blade | |
| Boom swing angle(Left/Right) | |
| Shipping method | 6 units in 20GP container 24units in 40GP container |
