Crawler Skid Steer Loader
If space is limited or you're in rough conditions but you need high lift capacity, the TOPWIN TWS50 Compact Track Loader is your perfect solution. It has the highest lifting height ideal for loading and unloading bricks, blocks and other palletized materials.
If space is limited or you're in rough conditions but you need high lift capacity, the TOPWIN TWS50 Compact Track Loader is your perfect solution. It has the highest lifting height ideal for loading and unloading bricks, blocks and other palletized materials.
SN | Model | LST50 |
(TWSS50) | ||
1 | Type | Tracked type |
2 | Operating load (kg) | 700 |
3 | Max Speed(km/h) | 10 |
4 | Rated flux (L/min) | 60 |
5 | Tire(track) model | 300X52.5 |
6 | Rated power (kW/HP) | 36 |
7 | Fuel tank capacity (L) | 50 |
8 | Self weight bucket (kg) | 2800 |
A | Bucket capacity (m 3 ) | 0.3 |
B | Overall operating height (mm) | 3350 |
C | Height to bucket hinge pin (mm) | 2770 |
D | height to top of cab (mm) | 2050 |
E | Height to bottom of level bucket(mm) | 2603 |
F | Overall length without bucket(mm) | 2300 |
G | Overall length with bucket(mm) | 2950 |
H | Dumping angle at maximum height(° ) | 40 |
I | Dumping height(mm) | 2100 |
J | Dumping reach(mm) | 790 |
K | Rollback o bucket on ground(° ) | 30 |
L | Rollback of bucket at full height(° ) | 104 |
M | Wheelbase(mm) | 1240 |
N | Ground clearance(mm) | 140 |
O | Angle of departure(° ) | 20 |
P | Front turning radius without bucket(mm) | 1064 |
Q | Front tuning radius(mm) | 1825 |
R | Rear tuning radius(mm) | 1264 |
S | Rear axle to bumper (mm) | 594 |
T | Tread width, centerline to centerline (mm) | 1102 |
U | Width (mm) | 1402 |
W | Bucket width (mm) | 1500 |
