Features:
1.Standard Ac Ac Drive And Eps Electric Power Steering, Better Feel And Lower Energy Consumption;
2.Smaller Body Size With Smaller Turning Radius And Right Angle Stacking Channels;
3.With The Speed Limit Function Of Turning, The Automatic Deceleration Of Turning Can Effectively Protect The Safety Of Goods And Operators;
4.Ergonomic Design: Easy To Operate Valve Stem And Multi-Function Intelligent Instrument, Some Models With Wheel Display Function;
5.Advanced Curtis Controller, More Stable And Safer;
Model |
| ERF16(BS) | ERF20(BS) | ||
Power type |
| Battery | Battery | ||
Operation Type |
| Seated | Seated | ||
Service weight（incl. battery） | kg | 3250 | 4000 | ||
Rated capacity | Q(kg) | 1600 | 2000 | ||
Load center | C(mm) | 500 | 500 | ||
Lift height | h3(mm) | 3000 | 3000 | ||
Fork dimension | l/e/s(mm) | 1070/100/35 | 1070/100/40 | ||
Front overhang | x(mm) | 220 | 215 | ||
Turning radius | Wa(mm) | 1700 | 1798 | ||
Max. gradeability |
| 10% | 10% | 10% | 10% |
Travelling speed ,laden/unladen | km/h | 8.5/10 | 8.5/10 | ||
Lifting speed ,laden/unladen | mm/s | 210/340 | 210/340 | ||
Lowering speed,laden/unladen | mm/s | 300/250 | 300/250 | ||
| General | Model | FD25 | |
| Rated capacity | kg | 2500 | |
| Load center | mm | 500 | |
| Power type | Diesel | ||
| Transmission | Hydraulic/Mechanical | ||
| Dimensions | Lifting height | mm | 3000 |
| Free lifting height | mm | 60 | |
| Turning radius | mm | 2450 | |
| Overall length | mm | 3605 | |
| Overall width | mm | 1160 | |
| Overall height (mast lowered) | mm | 2095 | |
| Overall height (mast raised) | mm | 4080 | |
| Overall height (overhead guard) | mm | 2095 | |
| Fork length | mm | 1070 | |
| Fork width | mm | 122 | |
| Fork thickness | mm | 40 | |
| Performance | Max. driving speed (with/without load) | km/h | 17/19 |
| Max. lifting speed (with load) | mm/s | 400 | |
| Max. traction (with/without load) | kn | 15/10 | |
| Gradeability (with/without load) | % | 15/20 | |
| Tilting angles (forward/backward) | ° | 6/12 | |
| Service weight | kg | 3600 | |
| Engine | Engine model | 490BPG | |
| Power | kw | 37 | |
| Rated speed | rpm | 2500 | |
| Wheel | Front overhang | mm | 451 |
| Wheel base | mm | 1640 | |
| Front tread | mm | 970 | |
| Rear tread | mm | 970 | |
| Front tire | 7.00-12 | ||
| Rear tire | 6.00-9 |
