Skid Steer Track Loader
Lst100 74Kw Skid Steer Loader With Rated Load 1200Kg
Main Features :
1 Compact Structure,Maneuverable Movement Suitable For Narrow Space Operation
2 Closed Cabin With Joystick Control System
3 Multi-Function With a Wide Range Of Attachments
4 Hydraulic Brake
5 Extend Wheelbase
6 High Flow Output
7 Double Accelerograph Control
8 Auto-Leveling System
1. Weichai Deutz Engine
2. Hydraulic Control Type: Main Pump Is Italy Bondioli Brand, Motor Is Italy Sai,
Multiway Valve And Pilot Handle Use Italy Hydqd.
3. Dual Accelerator Control Model: Manual Operated + Foot Operated, Easy To Operate .
4. Open-Type Cabin: With Shock Absorption Chair, Safety Guard Bar, Removable Rear Window.
5. Hydraulic Quick-Change Coupler Is The Same As Bob Cat,
And Is Suitable To Our Skid Steer Loader Attachments As Well As Foreign Attachments
SN | Model | LST100 (TWSS100) |
1 | Type | Tracked type |
2 | Operating load (kg) | 1200 |
3 | Max Speed(km/h) | 12/15 |
4 | Rated flux (L/min) | 88 |
5 | Tire(track) model | 320X84 |
6 | Rated power (kW/HP) | 74/100 |
7 | Fuel tank capacity (L) | 90 |
8 | Self weight bucket (kg) | 4500 |
A | Bucket capacity (m 3 ) | 0.55 |
B | Overall operating height (mm) | 4070 |
C | Height to bucket hinge pin (mm) | 3150 |
D | height to top of cab (mm) | 2160 |
E | Height to bottom of level bucket(mm) | 2983 |
F | Overall length without bucket(mm) | 3000 |
G | Overall length with bucket(mm) | 3700 |
H | Dumping angle at maximum height(° ) | 40 |
I | Dumping height(mm) | 2450 |
J | Dumping reach(mm) | 700 |
K | Rollback o bucket on ground(° ) | 30 |
L | Rollback of bucket at full height(° ) | 104 |
M | Wheelbase(mm) | 1500 |
N | Ground clearance(mm) | 200 |
O | Angle of departure(° ) | 20 |
P | Front turning radius without bucket(mm) | 1365 |
Q | Front tuning radius(mm) | 2200 |
R | Rear tuning radius(mm) | 1742 |
S | Rear axle to bumper (mm) | 938 |
T | Tread width, centerline to centerline (mm) | 1654 |
U | Width (mm) | 1994 |
W | Bucket width (mm) | 2030 |
