Compact Track Skid Steer Loader
Lst100 74Kw Skid Steer Loader With Rated Load 1200Kg
TOPWIN Mini Skid Steer Loader With Strong Power And Rich Attachments,
The TOPWIN Skid-Steer Loader Can Better Adapt To The Operations In Narrow Space
And Is An Ideal Tool For Road Construction, Municipal Maintenance, Port Handling,
Garden Maintenance, And Pasture Production,
Featuring Low Operation Cost And Remarkable Economic Benefits.
Features:
1) Compact Structure,Maneuverable Movement Suitable For Narrow Space Operation
2) Close Cabin With Joystick Control System
3) Double Accelerograph Control
4) Auto-Leveling System
5) Multi-Function With a Wide Range Of Attachments
6) Hydraulic Brake
7) Bigger Flow Hydraulic System Is Optional
8) With Air Conditioner
SN | Model | LST100 (TWSS100) |
1 | Type | Tracked type |
2 | Operating load (kg) | 1200 |
3 | Max Speed(km/h) | 12/15 |
4 | Rated flux (L/min) | 88 |
5 | Tire(track) model | 320X84 |
6 | Rated power (kW/HP) | 74/100 |
7 | Fuel tank capacity (L) | 90 |
8 | Self weight bucket (kg) | 4500 |
A | Bucket capacity (m 3 ) | 0.55 |
B | Overall operating height (mm) | 4070 |
C | Height to bucket hinge pin (mm) | 3150 |
D | height to top of cab (mm) | 2160 |
E | Height to bottom of level bucket(mm) | 2983 |
F | Overall length without bucket(mm) | 3000 |
G | Overall length with bucket(mm) | 3700 |
H | Dumping angle at maximum height(° ) | 40 |
I | Dumping height(mm) | 2450 |
J | Dumping reach(mm) | 700 |
K | Rollback o bucket on ground(° ) | 30 |
L | Rollback of bucket at full height(° ) | 104 |
M | Wheelbase(mm) | 1500 |
N | Ground clearance(mm) | 200 |
O | Angle of departure(° ) | 20 |
P | Front turning radius without bucket(mm) | 1365 |
Q | Front tuning radius(mm) | 2200 |
R | Rear tuning radius(mm) | 1742 |
S | Rear axle to bumper (mm) | 938 |
T | Tread width, centerline to centerline (mm) | 1654 |
U | Width (mm) | 1994 |
W | Bucket width (mm) | 2030 |
Skid Steer Loader Attachments
