Rough Terrain Forklift For Sale In Australia

Product Features



1.Adopt Low Noise Engine With Points Of Low Displacement And Environmental Protection.



2.Full Hydraulic Mechanic Automated Transmission And Guidance Device For Bendy And Handy Handling.



3.Large Hauling Potential From Its Double-Axle 4 Wheel Force For Extended Security And Stability.-Articulated Physique Format Reduces Turning Radius.



4.Fitted With Glamour Luxurious Seat For More Comfort.



5.Terrain Forklift Is Adaptable To More Than a Few Floor Conditions.



6.It Is Appropriate To Function On Smooth Soils,Grass,Terrain,Mine Websites And Many Different Rugged Surfaces.



7.Extensive Vary Of Attachments Is Accessible For This Mannequin To Lengthen Its Working Potential For Heavy Obligation Mining Tasks



The Rough Terrain Forklift Designed For Outdoor Harsh Environment, Streamlined Design, Smooth Lines, Beautiful Appearance,

Low Gravity Center, Excellent Stability, Equipped With Double Air Filter, Strong Air Purification.

The Forklift Mast Is Wider And Stronger Design, Better Vision, More Steady And Safety.

Ergonomic Design, Comfortable Operating, Lcd Display Instrument, Electronic Shift, Easy Operating; During Production Process,

We Use a Lot Tooling, To Keep Stable And Reliable Quality.

Limited Slip Gearbox With Special Differential Structure, Deep Pattern Driving Tires, Large Width Off-Road Tires,

Suitable For Rough Terrain Working.

Optional Configuration

Cab With Fan, Heater In The Cab, Dual Front Wheel,Solid Tires,High-Grade Seat, High Exhaust, Median Exhaust,

Tilting And Lifting Cylinder Sleeve,Dual Air Filter, Oil Type Air Filter,Fire Extinguisher Bottle, Fire Cover,

A490Bpg/C490Bpg495Bpg/498Bpg Diesel Engine, Eur Ii Japan Isuzu 4Jg2Pe-01 Engine,

 Japan Mitsubishi 4G64 Engine And Lpg System,2-Stage Mast With Full-Free Lift,Special Higher Mast,

3-Stage Mast With Full-Free Lift,
Lengthen Fork,Special Fork For Stone Factory,Special-Big Radiator,Radiator For Transmission Oil,Widen Fork Arm Carrier



Model	FD35	FD40
Rated Lifting Weight ,Kg	3500	4000
Load Center ,Mm	500	500
Power	Diesel	Diesel
Max. Lifting Speed (Full Load) ,Mm∕S	505/450	300
Max. Travel Speed (Full Load/Unload) ,Km/H	17∕19	18∕20
Max. Traction Force (Full Load/Unload), Kn	16∕11	16.5∕11.5
Grade-Ability (Full / No Load) ,%	15∕20	15∕20
H1 Lifting Height ,Mm	3000	3000
Free Lifting Height ,Mm	80	80
Mast Inclination (Α Front / Β Rear), Degree	6∕12	6∕12
Min. Turning Radius ,Mm	2540	2720
Min. Right Angle Channel ,Mm	2110	2320
Min. Ground Clearance ,Mm	135	135
A Overall Length (Including Forks) ,Mm	4000	4100
B Overall Width ,Mm	1230	1230
H Overall Height (Mast Retraction) ,Mm	2110	2110
H2 Overall Height (Full Extension Of Mast) ,Mm	4270	4270
H3 Overhead Guard Height ,Mm	2110	2110
A1 Front Overhang ,Mm	465	470
A2 Wheelbase ,Mm	1775	1900
B1 Wheel Treat Front ,Mm	1000	1060
B2 Wheel Treat Rear ,Mm	970	970
Front Tyre	28×9-15	250-15
Rear Tyre	6.50-10	6.50-10
Weight ,Kg	4660/4700	4900
B3 Fork Width,,Mm	122	150
H4 Fork Thickness ,Mm	45	45
Fork Bracket Height ,Mm	1225	1225
A3 Standard Fork Length ,Mm	1220	1220
Engine	China stage Ⅲ	China stage Ⅲ
Rated Power Kw	36.8	36.8
Speed At Rated Power Rpm	2500	2500
Maximum Torque Nm	157	185
Speed At Maximum Torque Rpm	1800	1800
Transmission	Mechanical	Mechanical
