Electric Skid Steer

Standard Layout: Wheel Loader, With One Stardard Bucket, 0.15 m3
With Imported Engine, Briggs &Stratton Gasoline Engine From Usa, 23Hp





  Contact Now
Product Details

 Specially Designed For Short Runs And Operation In Confined Places, Mmt80 Offers Operators a New Level Of Performance And Versability;

  With Quick Connects And An Arsenal Of  Available  Attachments, Mini Skid Steer Is Ready To Tackle a Variety Of Jobs With Ease;

  Equipped With a Nearly 1.3m Dump Height, The Mini Loader Saves Labor And Time;

 . Compact And Flexible Design Makes It Quite Easy And Convenient To Operate, Maintain And Repair.

 Perkins Tire 4 Diesel Engine,  Water Cool, 3 Cylinders, For Option


New Bobcat Skid Steer.jpg


Skid Steer Loader Specification


SnModelLs25Lst25
1ItemImperialMetricImperialMetric
ADeparture Angle20°20°20°20°
BCarry Position7 In178 Mm7 In176 Mm
CDumping Angle37°37°37°37°
DDumping Height50 In1279 Mm51 In1272 Mm
EDumping Distance33 In830 Mm33 In833 Mm
FGround Clearance7 In178 Mm6 In141 Mm
GFoot Pedal Ground Clearance7 In182 Mm7 In171 Mm
HMax. Height To Bucket Hinge Pin74 In1867 Mm74 In1869 Mm
IOverall Height53 In1358 Mm53 In1338 Mm
JOverall Length Without Bucket77 In1965 Mm77 In1959 Mm
KOverall Length With Bucket102 In2600 Mm103 In2619 Mm
LMax.Operating Height103 In2619 Mm103 In2626 Mm
MRollback Angle @ Carry Position20°20°21°21°
NRollback Angle @ Max.Height93°93°94°94°
OWheelbase31 In775 Mm36 In918 Mm
PMin.Turning Radius With Bucket64 In1624 Mm62 In1575 Mm
QOverall Width42 In1070 Mm43 In1103 Mm
RTrack Gauge//36 In903 Mm
SOverall Width With Standard Bucket49 In1250 Mm49 In1250 Mm


 Specially Designed For Short Runs And Operation In Confined Places, Mmt80 Offers Operators a New Level Of Performance And Versability;

  With Quick Connects And An Arsenal Of  Available  Attachments, Mini Skid Steer Is Ready To Tackle a Variety Of Jobs With Ease;

  Equipped With a Nearly 1.3m Dump Height, The Mini Loader Saves Labor And Time;

 . Compact And Flexible Design Makes It Quite Easy And Convenient To Operate, Maintain And Repair.

 Perkins Tire 4 Diesel Engine,  Water Cool, 3 Cylinders, For Option



Topwin Mini Loaders Was Established After Years Of Involvement With Both The Manufacturing And Contracting Side Of The Mini Skid Steer Loader Industry We Have a Unique Knowledge Of Machine Operation And Our Competitor's Machines. We Have Used This Knowledge As a Huge Advantage In Our Development With Careful Attention To Consumer Feedback And Competitors' Technical & Service Shortfalls. We Are Proud To Be Involved In The Industry And Look Forward To a Long And Successful Involvement. Our Aim Is To Provide Our Customers With Be's't Products And Best Support They Need To Run Their Businesses To Their Maximum Capacity With The Best Products Available.



With An Extremely Strong Engineering Background And Previous Manufacturing Knowledge, We Are Able To Meet The Requests And Needs Of The Most Demanding Customers.



Topwin Equipment Develops a Wide Range Of Lightweight Yet Heavy-Duty Machines That Generate An Impressive Amount Of Hydraulic Power To Lift More, Move More And Dig Faster Than Any Other Product On The Market. The Choice Of Contractors And Rental Organizations, The Topwin Is One Of The Most Versatile, Reliable And Productive Traction Units In The World.



The Topwin Compact Utility Loader Is An Innovative Machine That Reduces The Costs Of Performing Key Tasks And The Process Of Improving The Environments In Which People Live And Work. Developed To Replace Hand Labor, The Topwinprovides a Cost-Effective, Terrain-Friendly Solution For Landscapers, Irrigation Contractors, Plumbers, Electricians, And Property Owners As They Dig, Trench, Till, Auger, Demo, Place Materials, And Perform a Multitude Of Other Tasks.



Topwin Mini Skid Steer  Equipment Has Five Model Series Available: The New 4 In1 Bucket, The Dedicated Trencher And The Cg118, Cg823 And Cg827 Series Compact Utility Loaders, Built To Handle a Full Complement Of More Than 50 Universal Attachments. The Topwin Standard Quick-Attach System Enables The User To Quickly And Easily Switch From a Bucket To Forks To Auger Or Other Tools For Optimum On-The-Job Flexibility And Bottom-Line Performance.



 Product Details


Skid Steer Flail Mower.jpg          Skid Steer Loader Cabin        Skid Steer Loader Cabin

Skid Steer Hydraulic Connector    Skid Steer Loader Cabin           Skid Steer Loader Radiator

Skid Steer Loader Panel          Skid Steer Loader Pilot Lever        Skid Steer Loader Quick Hitch

Skid Steer Loader Panel        Skid Steer Loader Pilot Lever        Skid Steer Loader Quick Hitch


Skid Steer Loader Attachments

Skid Steer Loader Cabin


Company Profile

Shandong Topwin Machinery Co.,Ltd. (Topwin For Short) Is The One-Stop Solution Provider For Construction Machinery, Mining Machinery, Agricultural Machinery And Logistic Machinery In China.



With More Than 10 Years Experience In This Field, Topwin Has Served Various Clients From Usa, Canada, Mexico, Brazil, Argentina, Australia, Indonesia, Kazakhstan, Russia, Zimbabwe, Mozambique, Zambia, South Africa, Etc.. We Are Helping Our Clients To Succeed In Every Project By Offering High Cost-Effective And Reliable Machines.

tem

Model

TWS35

TWS45G

TWS60G

TWS65B

TWS100

TWSS65

TWSS100

1

Operating load (kg)

500

700

850

950

1200

1000

1200

2

Max Speed(km/h)

10

12

12

12

12/18

12/18

12/18

3

Rated flux (L/min)

60

75

75

80

80

75

88

4

Tire(track) model

8.5-15

10-16.5

12-16.5

12-16.5

12-16.5

320X84

320X84

5

Rated power (kW/HP)

29.5/40

37/50

45/61

55/75

74/100

55/75

74/100

6

Fuel tank capacity (L)

60

65

80

75

90

80

90

7

Self weight bucket (kg)

2300

3000

3200

3350

3550

3800

4500

8

Bucket capacity (m 3 )

0.3

0.4

0.5

0.5

0.55

0.5

0.55

A

Overall operating height (mm)

3300

3980

4000

4000

4070

3480

4070

B

Height to bucket hinge pin (mm)

2725

3080

3100

3100

3150

2900

3150

C

height to top of cab (mm)

2000

2140

2160

2160

2160

2150

2160

D

Height to bottom of level bucket(mm)

2558

2913

2933

2933

2983

2730

2983

E

Overall length without bucket(mm)

2300

2640

2750

2750

2880

2750

3000

F

Overall length with bucket(mm)

3080

3420

3490

3490

3580

3500

3700

G

Dumping angle at maximum height(° )

40

40

40

40

40

40

40

H

Dumping height(mm)

2050

2380

2400

2400

2450

2230

2450

I

Dumping reach(mm)

790

700

750

750

700

715

700

J

Rollback o bucket on ground(° )

30

30

30

30

30

30

30

K

Rollback of bucket at full height(° )

104

104

104

104

104

104

104

L

Wheelbase(mm)

897

991

991

1085

1185

1500

1500

M

Ground clearance(mm)

140

185

205

205

205

200

200

N

Angle of departure(° )

20

20

20

20

20

20

20

O

Front turning radius without bucket(mm)

1098

1168

1198

1204

1278

1298

1365

P

Front tuning radius(mm)

1760

1958

1958

2030

2144

2010

2200

Q

Rear tuning radius(mm)

1296

1630

1728

1706

1857

1714

1742

R

Rear axle to bumper (mm)

964

1108

1208

1082

1082

890

938

S

Tread width, centerline to centerline (mm)

1080

1450

1500

1500

1500

1462

1654

T

Width (mm)

1350

1720

1880

1880

1880

1782

1994

U

Bucket width (mm)

1400

1740

1880

1880

1880

1830

2030
